1xLGA1700Intel® Pentium® Processors Intel® Xeon® E processors 2xDDR5 4800 ECC UDIMM max. 64GB 1xPCI-E x16 (x16 Gen5 Link) Mini ITX (6.7” x 6.7”, 170mm x 170mm) FAN speed control Rack Ready (Rack and Pedestal dual use) ASUS Control Center 6xSATA 6Gb/s ports by 4 Mini-SAS HD connectors 1xM.2 connector(2280,support NVMe PCIe x4 link) 2xIntel® I210-AT2 + 1 x Mgmt LAN Aspeed AST2600 with 64MB VRAM (VGA from BMC) • On Board I/O 1xVGA Header (VGA from BMC) 1xTPM header 1xCOM port 2xFan Header , 4pin 1xChassis Intruder 2xFront LAN LED 1xPSU Power Connector (24-pin ATX power connector + 8-pin ATX 12V power connector) 1xM.2 Connector 2xUSB 3.2 Gen2 (rear) 2xUSB 3.2 Gen1 (rear) • Back I/O Ports 2xUSB 3.2 Gen2 2xUSB 3.2 Gen1 1xVGA port (VGA from BMC) 2x1 GbE LAN + 1 x Mgmt LAN On-Board ASMB11-iKVM for KVM-over-IP Monitoring CPU Temperature Fan RPM
